Details about USB C Triple Display MST 7-IN-1 Travel Dock, B794

Fullink B794 is 7-IN-1 USB C Triple Display MST Travel Dock with HDMI, DisplayPort, VGA, USB3.0 and Power Delivery connects to USB C or Thunderbolt 3 enabled laptops with up to 100W PD charging of your laptop. Compliant with Mac systems for M1 and M2.

mst travel dock b794


Ports:

4K HDMI: Connect a 4K display

4K DisplayPort: Connect to a DisplayPort display

VGA: Connect a VGA display

USB C: Connect storage devices and transfer data up to 10Gbps

USB C Power Delivery: Power a laptop or tablet with up to 100W power delivery

USB A (2): Connect storage devices and transfer data up to 5Gbps

A removable USB-C cable is easy to nest into the video hub for great mobility


Resolution

Single video mode: DisplayPort: Up to 3840x2160 30Hz / HDMI: Up to 3840x2160p 30Hz/ VGA: Up to 1920x1080p 60Hz

Dual video mode: DP+HDMI: Up to 1080p 60Hz (each display)/ DP+VGA: Up to 1080p 60Hz (each display)/ HDMI+VGA: Up to 1080p 60Hz (each display)

Triple video mode: DP+HDMI+VGA: Up to 720p 60Hz (each display)


Dimensions & Weight

Length: 127mm / 2.5 inch

Width: 63mm / 5 inch

Height: 13mm / 0.6 inch

Weight: 350g / 12.31 ounce


Certifications: ROHS.REACH

Material: Aluminum+Plastic

Service & Support: 1-year limited warranty

Available Color: Black


Package Contents

1x USB C Triple Display MST Travel Dock 7-IN-1

1x USB-C to USB-C cable

1x User Manual


Compatibility

OS compatibility: Windows 11/ ChromeOS Note: Only one video output is supported on the macOS (MST function not supported)

Compatible with: USB-C DisplayPort Alternate Mode (DP Alt Mode) and Thunderbolt 3 technology

Compatible with: DisplayPort 1.2 with MST graphics cards with AMD Eyefinity, NVIDIA Surround and Intel Multiple Displays technology
