Basic Parameter

Rated Voltage: 51.2V

Rated Capacity: 100Ah

Rated Energy: 5120Wh

Operation Parameter

Voltage Range: 44.8~56V

Charge Voltage Range: 55.2~56V

Cut-off Voltage: 44.8V

Recommend Charge Current: 50A

Max Charge Current: 100A

Max Discharge Current: 100A

Physical Parameter

Dimension: 442*470*154mm

Weight: 45kg

Communication Port: RS485, CAN

Display: LED+LCD

Terminal: M6

Environment Parameter

Humidity: 5~95% RH

Charge Temperature Range: 0~45℃

Discharge Temperature Range: -20~60℃

Storage Temperature Range: -20~45℃

Service Life

Cycle Life:＞6000Times (0.5C@ 25℃, 80% DOD)

Design Life: 15Years

Certification

Safety & Certification: CE, EMC, TUV (IEC62619), UL1973

Transportation: UN38.3
