Details about USB Type C to 8K@60Hz & 4K@144Hz HDMI Adapter 1193

This Fullink USB-C 3.2 to HDMI Adapter enables your USB-C and Thunderbolt 3/4 supported computer to connect to an 8K/4K Ultra HD display using Ultra High Definitin HDMI (2.1) Port . This USB-C to HDMI adapter is ideal for those engaged in high level computing, gaming or graphics by providing the highest performance available. With latest HDMI version throughput up to 48Gbps, the USB-C to HDMI adapter is ideal for when 8K video combined with a smooth, 60Hz frame rate and HDR is desired. Perfect companion for Apple Macbook, Macbook Pro/Air/iPad Pro, iMac, Mac Mini and Apple's new MacBook Pro 16".


Connect the USB-C end of the connector to your computer and plug your existing HDMI cable from the display into the other end of the adapter (HDMI cable sold separately). The video adapter converts the USB-C Graphics signal into an HDMI signal at up to UHD 8K 7860x4320 at 60Hz. Support of the 4:4:4 color format.  The video adapter will enable true RGB color without the visual color degradation that occurs in other color formats that use subsampling. When audio is desired, the USB-C adapter will also transmit up to 8 channel audio for an immersive audio and video experience.


USB-C-to-HDMI-adapter



Specifications


Input: USB-C 3.2 or Thunderbolt 3

■ Support 1/2/4 lanes up to HBR3 (8.1-Gbps) input

■ Built-in high-performance adaptive equalizer

■ Support 1-MHz AUX channel

■ Support DSC v1.2a and backward compatible with the former versions

■ Support DSC decoder and pass-through mode

■ Support max. resolution/timing up to 8K@60p / 4K@144Hz

■ Support CEC over AUX channel

■ Support LPCM audio format with max audio sample rate up to 8-channel 192KHz

■ Support HBR audio format up to 2-channel 768KHz

■ Support 3D audio format up to 16-channel 96KHz

■ Self-powered, no external power required


Output: HDMI 2.1 Female

■ Support maximum resolution/timing up to 8K@60p / 4K@144Hz with DSC

■ HDMI compliant transmitter, data rate up to FRL mode up to 12-Gbps per channel and TMDS mode up to 6-Gbps.

■ LPCM and Compressed Audio encoding formats

■ Support LPCM audio format with max audio sample rate up to 8-channel 192KHz

■ Support HBR audio format up to 2-channel 768KHz

■ Support 3D audio format up to 16-channel 96KHz Support DSC v1.2a and backward compatible with the former version

■ Support DSC pass-through mode


Material: Aluminum Shell

Dimensions: 59 x 26 x 11mm

Cable length: 216mm

Weight: 30g

Color: Silver

Operating temperature: 0 ℃ to + 40℃

Storage temperature: -10℃ to +70℃

Humidity: < 85% non-condensing

Certifications/Standards: FCC, CE, RoHS

Warranty: 1 years limited


USB Type C to HDMI Adapter



Product Features


Video Resolution up to 8K

■ Transform your USB-C port into a video powerhouse with support for 8K and 4K 144Hz.


Increase Work Efficiency

■ Can be connected to TV, Projector, Monitor. It's great for making presentations, participating in meetings, training or teaching lessons.


Perfect Gaming Experience

■ Ideal for gamers and other high-level computing requirements.

■ Stream your game to a big 8K or 4K monitor for better experience. Only work for phones that support DP Alt mode.


This USB Type C to HDMI Adapter with 4k 144hz resolution is a high-performance adapter that is ideal for gamers, video editors, and other professionals who require high-quality video output. This adapter is designed to provide a smooth and seamless video experience, with support for 4k resolution at 144hz. It is also compatible with a wide range of devices, including laptops, desktops, and gaming consoles, making it a versatile and convenient accessory for anyone who needs to connect their device to a high-resolution display. Overall, this adapter is a great choice for anyone who values high-quality video output and wants to take their gaming or video editing experience to the next level.



Compatibility


2020/2019/2018/2017/2016 MacBook Pro, 2020/2018 MacBook Air, 2015 MacBook (12 inch), 2020/2019/2018 iPad Pro, 2020 iPad Air, Windows laptop with Thunderbolt 3 or USB-C, Chrome OS laptop with USB-C, Any other device with USB-C.



*** 8K video requires a desktop computer with an Nvidia RTX 2060/2070/2080 or an AMD Radeon RX 6000 Series GPU. Laptops with 11th generation Intel Tiger Lake CPUs and Intel Iris Xe graphics, such as the Intel Evo certified laptops also support 8K (installation of the latest Intel graphics driver may be required).



Important Notes


■ 4K@144Hz and 8K support must be manually enabled on some 4K@144Hz and 8K televisions.

■ 8K video requires an 8K enabled USB-C port, an 8K enabled display and a HDMI 2.1 cable.

■ Please set the resolution you need in the Graphics Control Panel of your laptop when you connect an external monitor for the first time.

■ All Macbook, Macbook Pro, and Mac Mini with Apple M1 or Intel chips can only support a maximum resolution of 4K@60 Hz.

■ Do not support Nintendo Switch. (Switch requires an additional charging port)

■ Can only convert signal from USB-C to HDMI. This is not a bi-directional adapter.

■ 8K@60Hz or 4K@144Hz requires sourcing with DP 1.4 DSC 1.1/1.21
